1-8 General Information PLZ-4W
1.6 Options
Control flat cables
Control cable used to connect between the master unit and the slave unit (load
booster) and between slave units. The following two types of cables are available.
The two types of cables only differ in their length. The 550-mm PC02-PLZ-4W is
required to connect the master unit and the load booster.
Analog remote contorol connector kit (OP01-PLZ-4W)
A kit for connecting to the J1/J2 connector.
Model Code Length Application
PC01-PLZ-4W 84540 300 mm
Connect between
the master unit and the slave
unit (load booster) and between slave units
PC02-PLZ-4W 84550 550 mm Connect between the master unit and load booster
Pins 20 pcs.
Socket 1 pc.
Protection cover 1 set
