16
Power port (4PIN)
Screwdriver port
(6PIN)
RS232/PORT1 RS232/PORT2
BNK series
small torque
SKP-BE32HL
BN Anti-interference
cable
Connect Barcode
Scanner
Connect DAS
BNK series
power torque
SKP-40B-HL-800
SKP-40B-HL (BNK800 series)
BN Anti-interference
cable
Connect Barcode
Scanner
Connect DAS
Remark: Please switch the power controller HI/LO switch to "HI" position.
