19
：
NG will display when no load rotation
ONCE+CON/TWICE
+CON
ONCE: workpiece in position at once
TWICE: workpiece in position at two times
ONCE+CON: workpiece at position at once plus CONFIRM for
confirmation
TWICE+CON: workpiece at position at two times plus
Set up torque display unit.
MODE
STD: Standalone mode.
ADV: KL-AMS network system (WIFI/Ethernet) connection
ALIGNMENT
Calibration torque switch on/off
Press E/C key to start selection, use Up and Down key to change
to ON, and then press E/C key to confirm.
SET
MULTI : A Job cycle
LEARNING
Turn on auto-learning function; wait for the auto-learning to
complete (need to perform brake function), monitor will then
display the screw driving time, torque value, number of screw
turns, and such data will be saved. Above data cannot be 0 in
order to save the parameters after the auto-learning.
LEARNING
G1-G5：Set Barcode group
Second Code
P1-P99：Set PROGRAM Group
CL：Clear
DA：Disable Screwdriver Functions
EA：Disable Relieve
AS：Release Screwdriver lock status by OKALL
NS：Release Screwdriver lock status by NG
The maximum
length of Barcode
data is 16
characters
Name
Set Up Time and
Valu e
Function Interpretation
Factory Setting
Valu e
Action Limitation
RR/RS RT PT LL
AUTO FORWARD (RR/RS) V X X X
AUTO REV. TIME (RT) X V X X
AUTO STOP TIME (PT) X X V X
RECONFIRM TIME (LL) X X X V
Remarks: V - setting available, X - OFF
