Kilews KL - CTDS User Manual

17
2. Set Function Options and Operating Instructions
After switching on the power, to enter into the function menu, press the “P” key on the panel for 3 seconds,
following which password input is required to enter the menu.
Name
Set Up Time and
Value
Function Interpretation
Factory Setting
Value
[1] PROGRAM
1-99
Select program
1
BATCH
COUNT
1-250
Set up count value
Count number range is 0~250
5
TIME LIMIT
0.00-9.99 sec
Set up LT & HT functions
LT: Setting time and value is 0.00-9.99, Screwdriver stops or shut off
before Lo time setting, NG will be displayed on the status bar. It can
check whether the screw is properly fastened or not. (Lo time setting
can be used to detect cross threading or unfinished rundowns)
HT: Setting time and value is 0.00-9.99, Screwdriver stops or shut off
exceeded Hi time setting, NG will be displayed on the status bar. (Hi
time setting can be used to
detect stripped or oversize screw)
LT:0.00
HT:9.99
TORQUE
LIMIT
0.0-550.00
KGF.cm
Set up L & H functions
L & H: The options of Minimum Torque and Maximum Torque allow
the user to set up the acceptable torque range for each independent
application program. When the reaching torque is in the range, “OK”
will be displayed on the status bar, and the green LED light is lit up.
If the reaching torque exceeds such range, “Error in Minimum
Torque” or “Error in Maximum Torque”, “NG” will be displayed in
the status bar, and the red LED is lit up. The torque range value is
0-550KGF.
L:0.0
H:550.00
Name
Set Up Time and
Value
Function Interpretation
Factory Setting
Value
THREAD LIMIT
0.0-999.9
Turns
Number of screw turns
L & H: The options of Minimum number of turns and Maximum
number of turns allow the user to set up the acceptable number of
turns range for each rundown. The actual number of turns measured
refers to the motor turns/gear ratio; when the number turns reached
the range, “OK” is displayed in the status bar, and green LED light
of OK” is lit up. If the reaching number of turns exceeds such
range, “Error in Minimum number of turns” or “Error in Maximum
number of turns”, “NG” will be displayed in the status bar, and the
red LED is lit up.
L:0.0
H:999.9
SLOW START
TIME
L0-L9/
0.0-9.9 sec
Set up screwdriver slow start time and speed.
S: Set up slow start speed level, L0 (100%), L1~L9 (10%~90%).
(L0/L1/L2/L3/L4/L5/L6/L7/L8/L9)
T: Set up slow start time, slow start time is 0.0-9.9 sec..
S:L0
T:0.0
AUTO
FO RWA RD
RR:0.00-9.99 sec
RS:0.10-9.99 sec
Set up screwdriver reverse start time, then pause RS time, followed
by forward rotation until screwdriver shuts off.
RR: Set up the screwdriver reverse start time
RS: Set up the screwdriver pause time after reverse.
RR:0.00
RS:0.10
AUTO REV.
TIME
0.00-9.99 sec
Automatic reverse. Set up auto reverse time after screwdriver shut
off.
0.00
AUTO STOP
TIME
0.0-9.9 sec
Set up pre-fastening time.
0.00
RECONFIRM
TIME
0.00-9.99 sec
Set up re hit time after rundown complete.
0.00
ALARM SG.
TIME
0.00-9.99 sec
AT: OKALL signal output time
OT: OK signal output time
AT: 1.00
OT: 0.00
