HIGH PRESSURE CONTROL VALVE
Installation, Operation & Maintenance Guide
13
www.kimray.com
Model: PO, PC
DISASSEMBLY
Fig. 9-1
9 Removing Packing Box
Flip the Packing Box up side down and clamp the two at
sides of the Packing Box in vise and loosen Seat with an
adjustable wrench.
Leave the Seat attached to Cage. Insert a screw driver or
small bar through the Cage and unscrew. See Fig. 9-1
NOTE:
Leaving the Seat attached will prevent the Cage from
damaging the Cage wall or egg shaping.
Pull Stem and Cage out of Packing Box.
If Stem and Cage doesn’t come out then ip the Packing
Box over and tap the Stem with a hammer and a small
punch. Remove Cage from the Ball Stem and Spring
from the Packing Box.
