In line with development policy specifications may change without future notice. We made our best to guarantee the information accuracy included on this publication, the
A&AG S.r.l. doesn’t undertake responsibility for mistakes or imprecisions.
Copyright © 2013 A&AG S.r.l. All rights reserved.
Item no. UM_DD+_V02
DD+ / DQ+ models Specifications
KIND is a trademark of
A&AG S.r.l.
Via Montello, 19 - I-28066 Galliate (NO) ITALY
Tel. +39 0321865271 - Fax +39 0321861674
e-mail: info@kindaudio.com
www.kindaudio.com
Model DD+ 3600 DD+ 4000 DD+ 5000 DD+ 6400 DD+ 8000 DQ+ 5000 DQ+ 6000 DQ+ 7000 DQ+ 8000 DQ+ 10000
Number of channels 2222244444
Power Output Per Channel
1)
(all channels driven)
16 ohms per ch.
310 W 430 W 560 W 620 W 830 W 260 W 310 W 430 W 550 W 610 W
8 ohms per ch.
550 W 750 W 1050 W 1250 W 1500 W 450 W 550 W 750 W 1000 W 1250 W
4 ohms per ch.
1000 W 1250 W 1850 W 2200 W 2600 W 750 W 1000 W 1250 W 1700 W 2100 W
2 ohms per ch.
1800 W 2000 W 2500 W 3200 W 4000 W 1250 W 1500 W 1750 W 2000 W 2500 W
70V Direct Drive
2)
1000 W 1000 W 1700 W 1900 W 1900 W- 1000 W 1000 W 1500 W 1900 W
100V Direct Drive
2)
- 1250 W 2400 W 2500 W 2500 W --1250 W 2200 W 2500 W
Power Output Bridged Per Channels Pair
1)
16 ohms
1100 W 1500 W 2100 W 2500 W 3000 W 900 W 1100 W 1500 W 2000 W 2500 W
8 ohms
2000 W 2500 W 3700 W 4400 W 5200 W 1500 W 2000 W 2500 W 3400 W 4200 W
4 ohms
3600 W 4000 W 5000 W 6400 W 8000 W 2500 W 3000 W 3500 W 4000 W 5000 W
70V Direct Drive
2)
N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A
100V Direct Drive
2)
N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A
Performance With Gain
32 dB 32 dB 32 dB 32 dB 32 dB 32 dB 32 dB 32 dB 32 dB 32 dB
THD+N 20 Hz - 20kHz for 1 W @ 4 ohms <0.2% <0.2% <0.2% <0.2% <0.2% <0.2% <0.2% <0.2% <0.2% <0.2%
THD @ 1 kHz 1dB below clipping @ 4 ohms <0.35% <0.35% <0.35% <0.35% <0.35% <0.35% <0.35% <0.35% <0.35% <0.35%
Signal to Noise Ratio >102 dBA >101 dBA >101 dBA >100 dBA >100 dBA >101 dBA >101 dBA >100 dBA >100 dBA >100 dBA
Frequency Response (1 W @ 8 ohms) +0/-1dB 20Hz - 20kHz 20Hz - 20kHz 20Hz - 20kHz 20Hz - 20kHz 20Hz - 20kHz 20Hz - 20kHz 20Hz - 20kHz 20Hz - 20kHz 20Hz - 20kHz 20Hz - 20kHz
Damping Factor @ 8 ohms load, 10 Hz to 200 Hz >200 >200 >200 >200 >200 >200 >200 >200 >200 >200
Output Slew rate @ 8 ohms (input fi lter bypassed) 45V /uS 45V /uS 45V /uS 45V /uS 45V /uS 45V /uS 45V /uS 45V /uS 45V /uS 45V /uS
Input Impedance Balanced / Unbalanced 20k / 10kOhm 20k / 10kOhm 20k / 10kOhm 20k / 10kOhm 20k / 10kOhm 20k / 10kOhm 20k / 10kOhm 20k / 10kOhm 20k / 10kOhm 20k / 10kOhm
Input CMRR >50 dB >50 dB >50 dB >50 dB >50 dB >50 dB >50 dB >50 dB >50 dB >50 dB
Gain and Level
Input Sensitivity @ 4 ohms (32 dB gain) +/- 3 % 1.59 V 1.78 V 2.16 V 2.36 V 2.56 V 1.38 V 1.59 V 1.78 V 2.07 V 2.30 V
Input Gain Selectable (DIP switches on rear panel) 26, 29, 32, 35, 38, 41, 44dB
Default Gain 32 dB
Level Adjustment (per channel) Front panel potentiometer, 21 pos. stepped gain from -Inf to 0 dB
Front panel Indicators
Common Active on (normal status), Active off (mute); Hi temperature (blinking for power reduction and on for mute); Digital Signal Processor (DSP) present
Per channel Signal output -35 dB, -20 dB, -10 dB; Clip / Limit; Protect
Connectors and switches
Input connectors (per channel) Balanced: Neutrik Combo™ (XLR female and 1/4” jack), XLR pin 2 and TRS tip positive, and XLR male for link, pin 2 positive
Output connectors (per channel) Neutrik Speakon™ (bi-wiring connected)
Output bridge mode per two channels
A+B - ch. A is signal input source; C+D - ch. C is signal input source.
Rear panel 2 position DIP switches Ch.’s A+B (C+D) link/Bridge on
Rear panel 6 position DIP switches Ch. A / B (C / D) High Pass Filter 30 / 75 Hz on; Gain multiple selection
Power (on/off) switch on front panel
Output Circuitry
Class D
Power Supply
(R-SMPS) Regulated Switch Mode Power Supply with PFC (Power Factor Correction); The unit works anywhere in the world
Cooling
Two / three fans, front to rear air fl ow, temperature controlled speed; front panel removable dust fi lter
Amplifi er and Load Protection
Short circuit, open circuit, thermal, RF protection, mains over / lower voltage. On/off muting, DC fault shutdown, clip limiter
Power / Thermal
Operating voltage 95 - 265V AC - 50/60 Hz, min. power up voltage 80 V;
Current draw @ 230 V AC 1/8 power 4 ohms 1.7 A 2.1 A 2.9 A 3.4 A 3.9 A 2.7 A 3.4 A 4.1 A 5.3 A 6.4 A
Current draw @ 230 V AC 1/4 power 4 ohms 3.1 A 3.8 A 5.4 A 6.4 A 7.4 A 4.8 A 6.1 A 7.5 A 9.9 A 12.1 A
Current draw @ 230 V AC, idle 0.4 A 0.4 A 0.4 A 0.4 A 0.4 A 0.7 A 0.7 A 0.7 A 0.7 A 0.7 A
Soft start / Inrush current draw @230 V AC Yes / max. 2 A
AC cordset 230 V CE: 16 A, CEE7; 115 V ETL: 18A/NEMA L5-30P
Thermal emission (BTU/Huor) @ 1/8 power 4 ohms 464 517 645 720 805 759 865 972 1164 1334
Thermal emission (BTU/Huor) @ 1/4 power 4 ohms 677 784 1040 1189 1359 1079 1292 1505 1888 2229
Options
Digital Signal Processing board (KIND DSP board-1), handles
Dimensions (W/H/D)
W: 483 mm (19”), H: 88.9 mm (3.5” - 2 RU), Overal with optional handles D: 490 mm (19.29”), From front mounting rails D: 455 mm (17.91”)
Weight - Net / Shipping
10 kg (22 lbs.) / 13 kg (28.6 lbs) 11.5 kg (25.3 lbs) / 14.5 kg (31.9 lbs)
Approvals
CE EN55103-1 (Emissions), EN55103-2 (Immunity), EN60065, Class I (Safety)
Note 1) EIA 1kHz - 1% THD @ 230 V AC
Note 2) Internal 75Hz HPF enabled for this use
All specifi cations are subject to change without notice.
