SECTION 3
INSTALLATION OF FIRE
3.1 FITTING THE FUEL-BED LOGSET
a) The gravel material should then be first layed around the base of the
combustion chamber as shown below in Fig. 19, leaving the rear
section as shown to allow the fitting of Log “A”
Fig. 19
b) Place the largest Log “A” centrally onto the fuel-bed support behind the
burner flame strip. Ensure that the fuel-bed Log “A” is located centrally
in the firebox, and that the front edge is parallel with the rear face of the
burner flame strip as shown below in Fig. 20.
Fig. 20
Fuel-bed
Log “A” to be
fitted behind
burner flame
strip
16
A
