3
4
LINEAR
α
A B
LINEAR400230
LINEAR40024
90° 95 270
90° 195 200
110° 150 150
LINEAR500230
LINEAR50024
90° 200 250
110° 170 170
LINEAR400230 / LINEAR40024: 1100 mm
LINEAR500230 / LINEAR50024: 1300 mm
LINEAR400230
LINEAR40024: 107 mm
LINEAR500230
LINEAR50024: 142 mm
A
B
f
b
e
e
d
d
h
a
a
c c
g
