4) Setup Device Time
If you want to use the timer function, then must setup the system time after power on. Otherwise, the unit
will run it at mistake time. And when the backup battery out of voltage, then the time information will lose
and should re-setup the time again.
Command Return SMS Example
Setup PWD+DyymmddThhmm xx(Y)xx(M)xx(D)xx(H)xx(M) 1234D170102T1234
Inquiry PWD+D xx(Y)xx(M)xx(D)xx(H)xx(M) 1234D
5) Inquiry Current Status SMS command
SMS Command Return SMS Content
PWD+EE Model:
Version:
IMEI:
GSM Signal Value:
External Power Goes OFF/ON
DO1: Close/Open
DO2: Close/Open
-------
6) Setup 10 User Number, max 21 digits. ( Return 1~5 or 6~10 separately while setting.)
SMS Command Return SMS Content
Setup
PWD ＋ A ＋ series number+T+tel number
Notice: Series number =1~10
e.g.: 1234A3T008613570810254 to setup
008613570810254 as the 3
rd
number.
Tel1: ---
Tel2: ---
Tel3: 008613570810254
Tel4: ---
Tel5: ---
Inquiry PWD +A Return all numbers
Delete PWD +A+series number Return 1~5 or 6~10 numbers.
7) Setup Daily Report Time
SMS Command Return SMS Content
Setup PWD +DR+series number+T+xx+yy
(Notice: series number= 1~10, xx =00~23, stands for hour,
yy=00~59, stands for minutes. )
Daily SMS Report at: 1. xx:xx
2. ……
……
Inquiry PWD +DR Daily SMS Report at: xx:xx
Delete PWD +DRDEL+ series number Daily SMS Report at: xx:xx
8) SMS Control Relay Output
SMS Command Return SMS Content
Set DO Name PWD +DO+channel number+T+DO Name DOx:xxxx
Inquiry DO Name PWD +DO+ channel number<nn> DOx:xxxx
Delete DO Name PWD +DO+ channel number<nn> +DEL DOx:
Switch ON(Close) PWD +DOC+ channel number<nn> DOx: ON
DOy:ON
Switch OFF(Open) PWD +DOO+ channel number<nn> DOx: OFF
DOy:OFF
