Page 9 of 11 King Pigeon Hi-Tech. Co., Ltd. Ver 1.3
GSM
/
SMS
/
GPRS
/3G/
4G
Remote Relay Switch
Inquiry all DO Current
Status
PWD +DOE DO1: ON/OFF
DO2:ON/OFF
Set Pulse Output time PWD +DOP+ channel number<nn> +T+xxxx
(Notice: xxxx=0~9999seconds, =0 stands for always
close)
DOx Pulse Output Time:xxxx(S)
Inquiry pulse output
time
PWD +DOT+ channel number<nn> DOx Pulse Output Time:xxxx(S)
Pulse Output PWD +DOP+ channel number<nn>
9) Setup Timer(Total can setup 10 timer, every week to perform the preset actions, in timer action, the relay
exchange status will not alert SMS to users)
SMS Command Return SMS Content
Set Timer Relay Close Timer:
PWD+T+serial number(1~10)+Wx+Hhhmm+DOC
+ channel number
Relay Open Timer:
PWD+T+serial number(1~10)+Wx+Hhhmm+
DOO+ channel number
Notice:
x =0~7, 0 stands for everyday,1~7stands for
Monday ~ Sunday;
hh= 00~23, 2 digits, stands for hour;
mm=00~59, 2 digits, stands for minute;
Tips: Relay close time is according to Pulse
output time. Eg: Relay 1 pulse output time is
60s,then timer relay 1 close 60 seconds.
DOx: Weekly x hh:mm close
DOx: Weekly x: hh:mm open.
Inquiry PWD+T+serial number<nnnnnnnnnn> 1.
2.
…
Delete Timer PWD+T+Serial number+DEL
10) Reboot
SMS Command Return SMS Content
Reboot PWD+Reboot Restart the device
11) Setup the GPRS Parameter (APN/USER NAME/PASSWORD)
SMS Command Return SMS Content
Set PWD+AP+apn+#+username+#+userpassword
(Notice:apn=access point name)
Inquiry PWD+AP
Delete PWD+APDEL
APN:
User Name:
Password:
12) Setup the Server Parameter
SMS Command Return SMS Content
Set Server IP PWD+IP+ IP address+*+Server port Server:
Port:
