> (12b)
engine.
> The throttle interlock (12a) prevents unintentional
activation of the throttle control.
> Adjust the engine speed with the throttle control (12c).
The ignition switch electrically starts or stops the
Adjust the height of the front handle .
> Loosen the wing nut (15a) on the auxiliary handle (14) and
adjust the height (Fig. 9).
(14)
Adjustable auxiliary handle
14
15a
Fig.9
> (15a)Afterward tighten the wing nut .
Trimming head
The trimming head is intended to cut smaller types of
weed, lawn grass or similar soft vegetation.
> The trimming head is equipped with a bumper (22c)
helping to release and cut the trimming line (22a). Simply
tap the bumper on a firm surface and the spool will release
fresh trimming line (Fig. 10a).
(22)
Fig.10a
In more detail...
31
FPGTP25-2
Product functions
EN
