SPECIFICATIONS
KI 9800 Optical Light Source:
1310 or
1310/1550
nm Laser
1310/1625
nm Laser
1310/1490/
1550 nm
Laser
1310/1550/
1625 nm
Laser
635 nm
Laser
650 nm
Laser
850 nm
VCSEL
850 / 1300 nm
LED
660 nm
LED
Comments
Power (dBm) @
Fiber Type(m)
0
@ 9/125
0
@ 9/125
-4
@ 9/125
-4
@ 9/125
-2
@ 9/125
+7
@9/125
-2
@
62.5/125
-20 @ 62.5/125
-22.5 @ 50/125
-32 @ 9.5/125
-6
@ 1000 POF
 1 dB (@ 9/125,
62.5/125, 1000
POF only)
Short term
stability (dB)
0.04
1
0.06
1
0.04
1
0.06
1
N/A
N/A
0.12
1
0.01
0.01
For 15 min, typ 
 2C, after warm
up
Stability over
temp (dB)
0.6
0.6
0.6
0.6
N/A
N/A
0.8
0.35
0.35
Typical, over
temperature
 initial
tolerance (nm)
20
20
20
20
5
5
20
NA
5
At 25 C
 width, nm
3
3
3
3
3
3
< 1
NA
20
FWHM, typical
 nm/C
0.4
0.4
0.4
0.4
0.1
0.1
0.1
0.4
NA
Typical
Mode
Controlled
Source
NA
NA
NA
NA
NA
NA
Mode controlled
2
NA
Reconnection
repeatability
(dB)
0.1
0.1
0.1
0.1
0.1
0.1
0.1
0.05
NA
95 % confidence
Modulation
270 Hz, 1 kHz, 2 kHz  2 %
Blinking 2 Hz
NA
NA
NA
NA
Yes
Yes
NA
NA
Yes
Laser output
Adjustable over 3 dB in 0.1 dB steps
NA
NA
NA
1) ORL < -25 dB.
2) Multimode source: mode distribution @ 50/125 is compliant with the following standards: IEC 61280-4-1 {Ed.1.0}, TIA/EIA 526-14A and TIA TSB-178.

Kingfisher KI9600A Specifications
