Kingfisher NMRS1500 - Page 10

10
NMRS1500
Getting Started . . .
1. Handle
2. Upper handle bar
3. Middle handle bar
4. Power cord & plug
5. Handle assembly set (x4)
a. Locking knob
b. Bolt
6. Lower handle bar
7. Grip
8. Support
9. Screw (x2) (pre-assembled)
10. Castor
11. Wheel
12. Depth adjustment lever
13. Air vent
15. Grass catcher
16. Cord clip (x2)
17. Cord strain relief
18. Switch box
19. Lock-off button
21. Cutting device (scarifying cylinder)
22. Drive shaft
23. Bearing seat
24. Cutting device assembly sets
a. Bolt
b. Spring washer
25. Cutting device (raking cylinder)
26. Hex key 4 mm
All un-assembled parts
Motor
15
16
5
25
17
26
6
3
1
x4x2
Your product
