B2T Cot assembly instructions
4
Attaching the cot feet
NOTE: Please attach cot feet first to avoid damaging your end panels which
becomes the single bed base.
Attach 4 x cot feet to end
panels using 4 x D bolts
END PANELS WILL
NOT FREE STAND
WITH FEET ATTACHED
5
Attaching the fixed side
Connect the fixed side panel to the end
panels using 4 x I bolts.
(do not over tighten at this stage)
6
Placing base supports for newborn & baby positions
NOTE: Please place base supports into end panels with pin facing up
for base to sit on.
Place 4 x base supports into end panels,
make sure the pin is facing up.
Base at newborn
position.
Screw 4 x Base
supports to end
with 8 x C bolts.
Place 8 x C
bolts to cover
remaining
base holes.
Base at baby position.
This height should be
used when your baby
can sit up.
Screw 4 x base supports
to end with 8 x C bolts.
Place 8 x C
bolts to cover
remaining
base holes.
V 09/06
