5-32 CK25/30/35
If one of the rear wheels should slip,
use the differential lock. This will cause
both wheels to turn together. The dif-
ferential lock is engaged only when the
pedal is depressed.
(1) SMV Emblem
OPERATING THE TRACTOR ON A ROAD
OPERATING TECHNIQUES
(1) Differential Lock Pedal
(A) Release to “DISENGAGE”
(B) Press to “ENGAGE”
DIFFERENTIAL LOCK
MANUAL Type
704O542C
704O541C
HST Type
WARNING
!!
!!
!
To avoid personal injury due to
loss of steering control.
zz
zz
z Do not operate the tractor at high
speeds with the differential lock
engaged.
zz
zz
z Do not attempt to turn with the
differential lock engaged.
zz
zz
z When using the differential lock,
always slow the engine and
press the differential lock down.
zz
zz
z If the differential lock cannot be
released in the above manner,
step lightly on the brake pedals
alternately.
IMPORTANT
To Next Page
