Kioti CK30 - Page 74

5-36 CK25/30/35
(1) PTO (2) PTO Shaft Cover(1) Mid PTO Lever
(2) Rear PTO Lever
(1) REAR AND MID-PTO SPEED
MID-PTO LEVER(OPTION)
To use the Mid-PTO, shift the PTO le-
ver to engaged position. This shifting
requires clutch pedal operation.
(2) MID-PTO SHAFT COVER
The Mid PTO is available for KIOTI ap-
proved implements.
(1) Mid PTO (2) Mid PTO Shaft Cover
(3) Bolt
MID
PTO
PTO REVOLUTION [mn
-1
(rpm)]
5401st
2,000
REAR
PTO
1,0002nd
704O545C 704O546C 704O547C
WARNING
!!
!!
!
To avoid personal injury:
zz
zz
z Before operation, be sure to select
the correct PTO lever (Mid/Rear).
zz
zz
z Do not operate Rear-PTO driven
implements and Mid-PTO driven
implements at the same time.
