Kioti KL155 - Grille and Boom Attachment

INSTALLATION INSTRUCTIONS 14-3
STEP 6.
Install Front Grille. (Optional)
1. Grille W.A. - 1EA
2. Hex-Bolt-HT, M14-1.5P 40L – 4EA
Washer-Spring, M14 – 4EA
STEP 7.
Install Boom Ass’y
Hang the groove on the pin located on mounting frame.
STEP 8.
Hose "S"- shaped bend is fixed after the hose guide.
14
