3. CHECKING THE BRAKE PEDAL
1. Before operating the tractor on the
road or before applying the parking
brake, be sure to interlock the right
and left pedals as illustrated.
2. Use individual brakes to assist in
making sharp turns at slow speeds
(Field Operation Only).
Disengage the brake pedal lock and
depress only one brake pedal.
3. Be sure brake pedals have equal
adjustment when using locked to-
gether.
(1) BRAKE PEDAL (RIGHT AND LEFT)
4. RAISE THE IMPLEMENT.
The clutch is disengaged when the
clutch pedal is fully pressed down.
5. DEPRESS THE CLUTCH PEDAL
(1) Position Control Lever
(A) UP
(1) Clutch Pedal
S41O516A S41O517A
To avoid personal injury:
Applying one rear wheel brake
at a time can cause the tractor
to swerve or roll over at high
speeds.
WARNING
To avoid personal injury:
Do not release the clutch
suddenly, it may cause the
tractor to lunge forward un-
expectedly.
CAUTION
To Next Page
