K110sm5e2.doc
5-9
5. 2. 2 Replacing Motor
1. Remove Top Cover, Side Cover L, Operation Panel Assembly and Front Covers.
See [5.1.1 Removing Top Cover], [5.1.3 Removing Side Cover L], [5.1.4 Removing Operation
Panel Assembly] and [5.1.5 Removing Front Covers]
2. Disconnect the harness from Motor (1).
1
To Next Page
