KIP 600 - Page 50

K110sm5e3.doc
5-18
13. Remove each of Retaining Ring-E (22: E6), Polyslider Washer (23) and Bearing (24) on the
right.
14. Remove the Pan Head Screw (25: 4x8).
Remove P4 Pivot Washer (26) and P4 Twin Link 1 (27).
15. Remove the Pan Head Screw (28: 4x8).
Remove P4 Pivot Washer (29) and P4 Twin Link 1 (30).
16. Remove 2 Bearings (31).
22
22
23
23
24
25 25
26
27
28
28
30
29
31 31
