KIP 600 - Page 53

K110sm5e3.doc
5-21
22. Press Brackets (37) down to release Drive Roller 1 (38).
Slide Drive Roller 1 (38) left and remove it.
Replace it with a new one.
NOTE
The longer thin end of Drive Roller 1 should be placed at the left.
Left Ri
g
ht
37
38
37
38
