K110sm1e1.doc
1-4
1. 3 Appearance
1. 3. 1 Front
No. Part Name Function
1 Top Cover Scan originals.
Opened when cleaning or misfeed.
2 Original Tray Receives an ejected original.
3 Original Table Used to place an original.
4 Original Guide Guides an original to the scanner straight.
5 Lever Locks Top Cover.
6 Eject Guide Prevents an ejected original from misfeed.
1 5 23
4
4
5 6
To Next Page
