5. 3. 5 Replacing Sensor
1. Remove Top Cover, Shield Cover N and Base Plate.
See [5.1.1 Removing Top Cover], [5.1.2 Removing Shield Cover N] and [5.3.4 Removing Base
Plate].
2. Disconnect the harness from Sensor (1) (2) (3).
1
3
2
1
3
2
