3. Remove the screw (4) and remove Cover Sensor LG217L-3 (2) and Sensor PS117ND1 (3).
Replace Sensor with a new one.
NOTE
Sensor (2) is located on the back of Base Plate.
1 4 1
4 4 3 2
2 & 3
