7.4 Fan shield/Engine fixed plate
7.5 Guide Plate
7.6 Inspection
(1) Aluminum shell resistor (CG series)
Measure the resistance of aluminum shell resistor. Measuring error is ±5%.
Model 120V 230V\240V
Resistance
\consumption power
5Ω\50W 10Ω\50W
(2) Capacitor (CG series)
Measure the capacitance. Measuring error is ±5%.
Model 120V 230V\240V
Capacity /pressure 40uF\250V 20 uF\250V
43
