1.2 CHARACTERISTICS
Model IG2000/IG2000s/IG2000p/CG2000/CG2000s
Maximum output AC 2.0KVA
Rated output AC 1.6KVA
Rated output DC 100W
Rated frequency 50Hz 60HZ 60HZ
Rated voltage AC 230V 120V 240V
Rated voltage DC 12V
Rated current AC 7.0A 13.3A 6.7A
Rated current DC 8.3A
Power factor 1.0cosφ
Voltage variation rate Momentary
Average
Average time
10%max.
1.5%max.
3 sec. max.
Voltage stability ±1%
Frequency variation rate Momentary
Average
Average time
1%max.
1%max.
1 sec. max.
Frequency stability ±0.1%
Insulation resistance 10MΩmin.
AC circuit protector 9.3A(230V) 17.9A(120V) 9.0A(240V)
DC circuit protector 10A
Fuel tank capacity 3.5L
Fuel consumption (at rated load) 500g/KW.h
Operating hours (at rated load) 3.2h
Noise level (Zero load to full load) 58-65dB(A)/7m
