Kipor IG3000 Operation Manual

8
4. STARTING THE ENGINE
■When starting the generator after adding fuel for the first time or after
long term storage, or after running out of fuel, turn the fuel valve lever
to the "ON" position, then wait for 10 to 20 seconds before starting
the engine.
4.1 Starting Procedure
4.1(a) Turn the fuel valve lever to the ON position.
Fig.6
4.1(b) Pull the choke knob out to the CLOSED position
Do not use the choke if the engine is already warm or the ambient air temperature is high.
Fig.7
Fuel valve lever
Choke knob

Kipor IG3000 Specifications

General

Maximum Power	3.0 kW
Fuel Type	Gasoline
Rated Voltage	230V
Rated Current	12.2A
Rated Frequency	50Hz
Rated Power	2800 watts
Engine Type	4-stroke
Fuel Tank Capacity	13 L
Starting System	Recoil/Electric
