Kipor IG3000 Operation Manual

30
12. WHEEL KIT
The unit comes with the rubber mounting feet installed. If you wish to install the wheel kit, please
perform the following procedure.
Wheel Kit
1. Axle assembly (1)
2. Locking swivel wheel (2)
3. Bolt M8X16 (4)
4. Wheel (2)
5. Bolt M6X16 (8)
A. Wheel assembly:
First remove all four rubber mounting feet.
Put a washer on each side of the wheel then slide them on the axle
securing with a lock pin.
1. Wheel (2)
2. Axle (1)
3. Lock pin (2)
4. Washer (4)
B. Locking swivel wheel.
Secure each locking swivel wheel with 4 M6X16 bolts.
1. Locking swivel wheel
2. Bolt M6X16

Kipor IG3000 Specifications

General

Maximum Power	3.0 kW
Fuel Type	Gasoline
Rated Voltage	230V
Rated Current	12.2A
Rated Frequency	50Hz
Rated Power	2800 watts
Engine Type	4-stroke
Fuel Tank Capacity	13 L
Starting System	Recoil/Electric
