47
Model KDE25SS KDE30SS KDE35SS
Rated frequency Hz 50 60 50 60 50 60
KVA 20 24 23 28 30 35
Rated output
KW 20 24 23 28 30 35
Rated voltage V 115/230 120/240 115/230 120/240 115/230 120/240
Rated current A 174/87 200/100 200/100 234/117 260/130 292/146
Rated rotation speed r/min 1500 1800 1500 1800 1500 1800
Phase no./ Excitation mode
Single phase /
Brushless self-excitation and constant voltage (with AVR)
Power factor (cosφ) 1.0
Insulation grade H
Generator
Pole number 4
Model KM493G KM493ZG KD4105G
Type
Four cylinder,
4-stroke, direct
injection
Four cylinder,
4-stroke, direct
injection,
supercharged
Four cylinder,
4-stroke, direct
injection
Cylinder No.-Bore × Stroke mm 4-93×102 4-93×102 4－105×125
Displacement L 2.771 2.771 4.33
Compression ratio
18.2:1
17.5:1
Rated power KW（r/min） 23.2/1500 30/1800 28.5/1500 36.9/1800 40.2/1500 47.6/1800
Fuel type 0# (summer), -10# (winter), -35# (cold) light diesel
Lube oil type
Above CD grade, SAE 10W30 or 15W40
Fuel consumption g/kw·h
≤320
≤320 ≤300 ≤300 ≤300
Fuel tank capacity L 95 95 95
Engine
Continuous running time h 11 9 10 9 8 7
Overall dimension LXWXH
mm 1900×950×1200 2250×950×1300
Net weight kg 960 985 1220
Starting mode 12V electric starting
Noise at zero load dB(A)/1m 68 70 68 70 68 70
Noise at rated load dB(A)/7m 51 53 51 53 51 53
Set
Structure type
Ultra silent
