48
(2) Three-phase
Model KDE13SS3 KDE20SS3
Rated frequency Hz 50 60 50 60
KVA 10.6 13.1 17 20
Rated output
KW 8.5 10.5 13.6 16
Rated voltage V 230/400 240/416 230/400 240/416
Rated current A 15.3 18.2 24.5 27.8
Rated rotation speed r/min 1500 1800 1500 1800
Phase no./ Excitation mode
Three phase /
Brushless self-excitation and constant voltage (with AVR)
Power factor (cosφ) 0.8(lag)
Insulation grade F
Generator
Pole number 4
Model KD388G KD488G
Type
Three cylinder, 4-stroke, direct
injection
Four cylinder, 4-stroke, direct
injection
Cylinder No.-Bore × Stroke mm 3-88×90 4-88×90
Displacement L 1.642 2.19
Compression ratio
18.2:1
Rated power KW(r/min) 12.3/1500 14.8/1800 16.4/1500 19.6/1800
Fuel type 0# (summer), -10# (winter), -35# (cold) light diesel
Lube oil type
Above CD grade, SAE 10W30 or 15W40
Fuel consumption g/kw·h
≤340 ≤320
Fuel tank capacity L 65 65
Engine
Continuous running time h 18 14 12 9
Overall dimension
LXWXH
mm 1570×780×1050
Net weight kg 685 720
Starting mode 12V electric starting
Noise at zero load dB(A)/1m 68 70 68 70
Noise at rated load dB(A)/7m 51 53 51 53
Set
Structure type
Ultra silent
