Kipor KDE45SS3 User Manual

49
Model KDE30SS3 KDE35SS3
Rated frequency Hz 50 60 50 60
KVA 24 28 28 35
Rated output
KW 19.2 22.4 22.4 28
Rated voltage V 230/400 240/416 230/400 240/416
Rated current A 34.6 38.4 40.4 48.6
Rated rotation speed r/min 1500 1800 1500 1800
Phase no./ Excitation mode
Three phase /
Brushless self-excitation and constant voltage (with AVR)
Power factor (cosφ) 0.8(lag)
Insulation grade H
Generator
Pole number 4
Model KM493G KM493ZG
Type
Four cylinder, 4-stroke, direct
injection
Four cylinder, 4-stroke, direct
injection
Cylinder No.－Bore × Stroke mm 4－93×102 4－93×102
Displacement L 2.771 2.771
Compression ratio
18.2:1
Rated power KW（r/min） 23.2/1500 30/1800 28.5/1500 36.9/1800
Fuel type 0# (summer), -10# (winter), -35# (cold) light diesel
Lube oil type
Above CD grade, SAE 10W30 or 15W40
Fuel consumption g/kw.h
≤320
≤320 ≤300
Fuel tank capacity L 95 95
Engine
Continuous running
h 11 9 10 9
Overall dimension
mm 1900×950×1200
Net weight kg 960 985
Starting mode 12V electric starting
Noise at zero load dB(A)/1m 68 70 68 70
Noise at rated load dB(A)/7m 51 53 51 53
Set
Structure type
Ultra silent

Kipor KDE45SS3 Specifications

General

Brand	Kipor
Model	KDE45SS3
Category	Inverter
Language	English
