50
Model KDE45SS3 KDE60SS3
Rated frequency Hz 50 60 50 60
KVA 37 45 50 60
Rated output
KW 29.6 36 40 48
Rated voltage V 230/400 240/416 230/400 240/416
Rated current A 53.4 62.5 72.2 83.8
Rated rotation speed r/min 1500 1800 1500 1800
Phase no./ Excitation mode
Three phase /
Brushless self-excitation and constant voltage (with AVR)
Power factor (cosφ) 0.8(lag)
Insulation grade H
Generator
Pole number 4
Model KD4105G KD4105ZG
Type
Four cylinder, 4-stroke, direct
injection
Four cylinder, 4-stroke, direct
injection
Cylinder No. － Bore× Stroke mm 4－105×125 4－105×125
Displacement L 4.33 4.33
Compression ratio
17.5:1
Rated power KW（r/min） 40.2/1500 46.7/1800 49/1500 58/1800
Fuel type 0# (summer), -10# (winter), -35# (cold) light diesel
Lube oil type
Above CD grade, SAE 10W30 or 15W40
Fuel consumption g/kw·h
≤300 ≤290
Fuel tank capacity L 95 95
Engine
Continuous running time h 8 7 6.5 6.5
Overall dimension LXWXH
mm 2250×950×1300
Net weight kg 1270 1310
Starting mode 12V electric starting
Noise at zero load dB(A)/1m 68 70 68 70
Noise at rated load dB(A)/7m 51 53 51 53
Set
Structure type
Ultra silent
