6
2.3 SMART Energy-saving switch
ON：
Generator would be at idle state if electrical appliance is disconnected from engine;
Engine would return to normal speed once connected with appliance. This equipment
is to reduce oil consumption in running.
CAUTION
■ (SMART) energy saving switch cannot run effectively when greater instant
power is needed.
■ Shut down energy saving switch to reduce voltage variation when generator is
connected with high electrical load.
■ Close energy saving switch during DC operation.
OFF：
Indicates that smart energy saving switch is closed and engine is at high rotation
speed.
2.4 LCD parameters display
2.4.1 Single-voltage LCD－230V
LCD will display the following parameters in cycle
after powered on:
No. Parameters Unit Note
1 Genset voltage 1 V V
1 A
2 Genset current
0.1 A
A
3 Genset frequency 0.1 Hz Hz
4 Battery voltage 0.1 V V
5 Accumulated running time 0.1 Hour Hr
CAUTION
■ LCD back light lights for 10 seconds then goes out automatically once pushed
button.
■ When the current displayed parameter is not “genset voltage”, displayed
parameter will switch to “genset voltage” automatically after 30 seconds.
