7
2.4.2 Dual-voltage LCD－120/240V
After the system is powered on, self-check indicator lights and buttons are pushed
continually, the following parameters will be displayed in cycle:
(1) Displayed parameters in series connection：（120/240V simultaneous output）
No. Parameters Unit Note
1 Genset AB-Phase voltage 1 V V
2 Genset A-Phase voltage 1V V
3 Genset B-Phase voltage 1V V
1 A
4 Genset A-Phase current
0.1 A
A
1 A
5 Genset B-Phase current
0.1 A
A
6 Genset frequency 0.1 Hz Hz
7 Battery voltage 0.1 V V
8 Accumulated running time 0.1 Hour Hr
(2) Displayed parameters in parallel connection:（120V output）
No. Parameters Unit Note
1 Genset voltage 1 V V
1 A
4 Genset current
0.1 A
A
6 Genset frequency 0.1 Hz Hz
7 Battery voltage 0.1 V V
8 Accumulated running time 0.1 Hour Hr
CAUTION
■ LCD back light lights for 10 seconds then goes out automatically once pushed
button.
■ When the current displayed parameter is not “genset voltage”, displayed
parameter will switch to No.1 listed parameters after 30 seconds.
■ Parameter will be displayed as“――――――” when voltage selection switch is at
incorrect position.
