Kirby Avalir User Manual

11
GETTING STARTED
Assembling the Unit
1
Assemble the Upright Handle by sliding the two pieces
together. Screw in the cord hook and spring to secure.
2
Push the base of the Upright Handle into the connection on
the top of the unit.
3
Attach the Bag Latch Tab on the Outer Permanent Bag to
the Upright Handle.
4
With the arrows lined up, slide the Mini Em-Tor® collector
on to the Air Exhaust Port. Rotate it toward the unit to lock
in place.
5
Flip out the handle on the Belt Lifter on the Power Nozzle.
Turn it counterclockwise until the red arrows line up.
The hook should catch and stretch the Belt inside the Power
Nozzle.

Kirby Avalir Specifications

General

Type	Upright
Power Source	Corded Electric
Bagged/Bagless	Bagged
Filtration	HEPA
Weight	23 lbs
Model	Avalir
Category	Vacuum Cleaner
Warranty	3-year limited warranty
Attachments	upholstery tool
