TR850, TR850G DMR Repeater Instruction Manual
23
7 Recommend Duplexer Parameters
Model
SGQ-450 A / D
Frequency Range(MHz)
380~520
Bandwidth(KHz)
±400
Frequency Spacing(MHz)
10
Insertion Loss(dB)
<1.0
Isolation (dB)
>80
Suppression(dB)
>80
V.S.W.R
<1.3
NormaI lmpedance(Ω)
50
Max Power Input(W)
30 / 50
Standard Termination
N/BNC
Dimensions(mm)
223×154×31.5
223×191×39
Weight(KG)
1.2 / 2.0
