KIRLOSKAR DSM Series - Component for Gland Packed Pumps; Component for Mechanical Seal Pump

17
PART NO DESCRIPTION QTY
602 PIPE PLUG FOR SEALING 1
604 PIPE PLUG FOR STUFFING BOX 2
610.2* CYLINDRICAL PIN FOR INTER STG DIAPHRAGM 1
610.1* CYLINDRICAL PIN FOR WEARING RING. 2
611 TAPER PIN FOR T/B CASING 2
640 RIVET TB NAME PLATE. 4
668 HEX.SOCKET GRUB SCREW 1
670 DUTY NAME PLATE 1
731 STUD FOR SPLIT OR NON-SPLIT GLAND 4
7.1.3.2 Component for Gland packed pumps
PART NO DESCRIPTION QTY
229* GLAND 2
224* CLAMPING PLATE FOR SPLIT GLAND 2
227.1* SPLIT LANTEN RING 1
228 STUFFING BOX BUSH 2
310* SHAFT SLEEVE 2
430* GLAND PACKING 2 Set
7.1.3.2 Component for Mechanical seal pump
PART NO DESCRIPTION QTY
310* SHAFT SLEEVE FOR MECHANICAL SEAL 2
230* MECHANICAL SEAL 2
231* MECHANICAL SEAL COVER 2
* Parts for two years normal working of the pumps.
** These parts should be included in the order, while ordering top and bottom casing.
N Quantity depends upon pump type.
