IOM/DSMT/0010/01 Issue Date: 13/10/2000
Page : Page 10/14 Last Revision Date:
PART
NOS.
DESCRIPTION
NO. OF
PUMP
586
572
581
631
611*
610*
601
600
602
604
430
519*
522*
441
560
670
264*
263*
336*
550
223*
979.1
979.2
240.1
240.2
415*
500*
199*
582
624
223*
330*
410*
201*
204*
Bolts with nuts for 274
Bolts for upper and lower half casing
Nuts for Lower half casing
Hex screw for bearing cover
Taper pin with washes and nuts for lower and upper
half casing
Cylindrical pin
Drain plug for casing
Plug for Suc. & Del. Pressure gauge connections
Plug for sealing
Plug for st. box leakage water
Gland packing
Paper packing between 122 & 123
‘O’ ring for shaft sleeve
Grease nipple for lubrication
Nylon tube for sealing
Duty name plate
Cylindrical roller bearing SKF N 311 or equivalent
Double row angular contact ball
Bearing SKF:7310 BG or equivalent
Bearing lock nut ND/NDE
Wheel cock
Gland (non split)
Insert DE
Insert NDE
Bearing Housing DE
Bearing housing NDE
Lock Washer
Oil Seal
Shoulder Ring
Gland Nut
Washer
Gland
Impeller nut
Lock washer
Distance Sleeve
Inter stage ring
4
1 set
1 set
8
2
2
2
2
1
2
1set
1
2
2
1
1
1
1
2
1
2
1
1
1
1
2
2
2
4
4
2
2
2
2
1
* Recommended spares.
