IOM/DSMT/001/01 Issue Date: 13/10/2000
Page : Page 10/12 Last Revision Date:
6.4.9 Insert the lantern ring at non-driving end side at a position indicated in technical data
chart (e.g. 2+L+3).
6.4.10 Fix gland (229) on the shaft. Tighten the stuffing box packing by tightening the
gland nuts (300).
While tightening the glands, please see that the unit can be rotated by hand.
6.4.11 Connect the Nylon pipes for sealing connection. Fix air vents, priming funnel and
grease nipples. Fix the nameplate (670) on NDE cartridge.
This completes the re-assembly.
While ordering spares, specify nameplate details, particularly machine numbers given
in enclosed spare parts list. Also specify quantity required.
7. SPARE PART LIST
PART
NOS.
DESCRIPTION
NO. OF
PUMP
122
123
157*
158*
180*
190*
204*
241
253
260*
270
271
274
310*
229*
227*
350*
236
450
320 *
321*
335*
Casing half upper
Casing half lower
Impeller, 1
st
stage
Impeller, 2
nd
stage
Pump shaft
Wear ring
Interstage ring
Cartridge for bearing, DE
Cartridge for bearing, NDE
Ball bearing, DE
Bearing cover, DE
Bearing cover, NDE
Bearing Cap
Shaft sleeve, DE/NDE
Gland, DE/NDE
Lantern ring
stuffing box bush
Water Deflector DE/NDE
Air vent
Impeller key
Coupling key
Bearing nut
1
1
1
1
1
2
1
1
1
1
1
1
2
1
2
2
2
1
2
1
1
1
