IOM/DSMT/001/01 Issue Date: 13/10/2000
Page : Page 11/12 Last Revision Date:
PART
NOS.
DESCRIPTION
NO. OF
PUMP
586
572
&581
631
611
610
601
600
602
604
430*
519*
522*
441
560
670
264*
263*
336*
550
573
300
610.1
610.2
Bolts with nuts for 274
Bolts with nuts for upper and
Lower half casing
Hex screw for bearing cover
Taper pin with washes and nuts for lower
and upper half casing
Cylindrical pin
Drain plug for casing
Plug for Suc. & Del. Pressure gauge
connections
Plug for sealing
Plug for st. box leakage water
St. box packing
Paper packing between 122 & 123
‘O’ ring for shaft sleeve
Grease nipple for lubrication
Nylon tube for sealing
Duty name plate
Cylindrical roller bearing
SKF N 311 or equivalent
Double row angular contact ball
Bearing SKF:7310 BG or equivalent
Bearing lock nut ND/NDE
Wheel cock
Hex bolt for Bearing cap
Eye bolt for gland
Cylindrical Pin for wear ring
Cylindrical Pin for interstage diaphragm
4
-
8
2
2
2
2
1
2
1set
1
2
1
1
1
1
2
1
* Recommended spares.
