KIRLOSKAR DSM Series User Manual

IOM/DSMT/001/01 Issue Date: 13/10/2000
Page : Page 6/12 Last Revision Date:
4.5.7 Technical data Chart
PUMP TYPE
“DSM” ---------------->
100/36 125/40 150/46
FLANGE SIZE IN MM
DEL. x SUC.
100 x 125 125 x 150 150 x 200
BALL BEARING NO.
SKF OR EQUIV.
DRIVING END
6307 6309 N311
NON DRIVING END 3307 3309 2 x 7310 BG
QTY. OF GREASE
PER BRG. Cms 100 100 200
ST. BOX PACKING
SIZE IN MM.
SIZE x LENGTH 10 SQ x 2250 12 SQ x 2850 12 SQ x 3200
POSITION OF
LANTERN RING (L)
FROM IMPELLER
SIDE (NDE SIDE) 2+L+3 2+L+3 2+L+3
NO. OF PACKING RINGS
DE (Lantern ring is not
required of DE side) 6 6 6
NDE 5 5 5
COUPLING TYPE FLEXIBLE
JOY TYPE
KC 276
PIN
BUSH TYPE
S 260
PIN
BUSH TYPE
S 290
