PISTON & CON ROD ASSEMBLY
Sr.
Part No.
Description
Qty.
Remark
*1
P05.0723.040.0.PR
PISTON & CON ROD ASSEMBLY
1
CONSISTING OF SR.
NO. 2 TO 11
2
P05.0723.010.0.PR
PISTON
ASSEMBLY COMPLETE
1
CONSISTING OF SR.
NO. 3,7
*3
CC3.005.50.0.00
PISTON ASSEMBLY WITH PIN
1
CONSISTING OF SR.
NO. 4 TO 6
4
CC3.005.59.0.PR
PISTON
1
5
CC3.005.57.0.PR
PISTON PIN
1
6
CC3.005.006.0.00
RETAINER CLIP OF PISTON PIN DIA 21
2
7
CC3.005.30.0.00
PISTON RING GROUP
1
CONSISTING OF SR.
NO. 8 TO 10
*8
CC3.005.001.0.00
TOP COMPRESSION CHROME PLATED RING
(FOR 78 DIA PISTON)
1
NOT ILLUSTRATED
*9
CC3.005.002.0.00
TAPER FACE SECOND COMPRESSION RING
(FOR 78 DIA PISTON)
1
NOT ILLUSTRATED
*10
CC3.005.003.0.00
CHROME CONFORMABLE OIL RING (FOR 78
DIA PISTON)
1
NOT ILLUSTRATED
*11
CC3.003.040.0.00
CON ROD ASSEMBLY COMPLETE
1
CONSISTING OF SR.
NO. 12 TO 15
12
CC3.005.008.0.00
CONNECTING ROD
1
13
CC3.005.007.0.00
CONNECTING ROD BUSH
1
14
CC3.005.009.0.00
CONNECTING ROD BEARING
2
15
CC3.005.011.0.00
CONNECTING ROD BOLT M7 x 1 x 38
2

.,5/26.$52,/(1*,1(6/,0,7('

$.LUORVNDU*URXS&RPSDQ\
