GEAR BOX ASSEMBLY
SR.NO. PART NO PART NAME QTY.
1 P08.D003.085.0.00
D
2 P08.D003.051.0.00 CLUTCH FORK ROLLER ASSEMBLY
3 P08.D003.052.0.00 FORK
4 57.507.18.000 PLAIN WASHER M18
5 P08.D003.041.0.00 CASE
6 P08.D003.001.0.00 DOUBLE END STUDS M8×41
7 P08.D003.042.0.00 RATCHET CLUTCH
8 P08.D003.053.0.00 SPLINE SHAFT
9 P08.D003.002.0.00 DIFFERENTIAL CLUTCH SPRING
10 50.911.06.016 FLANGE BOLTS M6*16 1
11 P08.D003.012.0.00 STAY FIXED HEX NUT M6
12 P08.D003.003.0.00 C CLIP Φ6 1
13 P08.D003.071.0.00 CLUTCH BRACKET PULLEY 1
14 P08.D003.081.0.00 SHIFTING FORK BRACKET 1
15 P08.D003.021.0.00 REVERSE RETURN SPRING 1
16 P08.D003.022.0.00 OIL SEAL Φ14*Φ22*4 3
