CRANKSHAFT, CAMSHAFT, BALANCER SHAFT & FLYWHEEL
ASSEMBLY
Sr.
No.
Part No. Description
Qty.
Remark
*1
P08.0707.1
10.0.PR
CRANKSHAFT ASSEMBLY
FOR DLX
1
CONSISTING OF SR.
NO. 2 TO 6
2 P08.0707.1
09.0.PR
CRANKSHAFT SUITABLE FOR CONICAL
SLEEVE
1
3
CC3.006.005.0.00
CRANKSHAFT TIMING GEAR
1
4
CC3.006.008.0.00
BALANCING SHAFT DRIVING GEAR
1
5
CC1.003.016.0.00
PLUG 6 x 8
1
6
CC1.003.013.0.00
KEY 5 x 12
3
*7
P05.0707.020.0.PR
FLY WHEEL ASSEMBLY
1
CONSISTING OF SR.
NO. 8 TO 17
8
CC3.006.010.0.00
FLYWHEEL
1
12
CC3.006.013.0.00
NUT FLYWHEEL M18
1
13
CC3.006.012.0.00
FLYWHEEL NUT WASHER
1
15
CC1.005.33.0.00
FLANGE BOLT M6x 1 x 20
3
16
CC3.006.017.0.00
CABLE HOLDER CLAMP
1
17
N11.051.06.0.00
FLANGED SCREW - M6 x 1.0 x 12 mm
1
Ύ1ϴ
CC3.007.10.0.00
CAMSHAFT ASSEMBLY
1
CONSISTING OF SR.
NO. 19 TO 24
19
CC1.003.022.0.00
SLEEVE OF FUEL PUMP
1
20
CC3.007.001.0.00
PUSH ROD
2
21
CC3.007.002.0.00
TAPPET
2
22
CC1.003.025.0.00
KEY 4 x 12
1
23
CC3.007.003.0.00
CAMSHAFT
1
24
CC3.007.004.0.00
CAMSHAFT TIMING GEAR
1
ΎϮ5
CC3.006.010.0.0
BALANCER
SHAFT ASSEMBLY
1
CONSISTING OF SR.
NO. 26 TO 29
26
CC3.006.001.0.00
BALANCER SHAFT
1
27
CC1.003.009.0.00
KEY 5 x 7
2
28
CC3.006.002.0.00
BALANCER SHAFT TIMING GEAR
1
29
CC3.001.010.0.00
BALL BEARING 6202
2

.,5/26.$52,/(1*,1(6/,0,7('
$.LUORVNDU*URXS&RPSDQ\
