KIRLOSKAR KMW MIN T 8 DLX User Manual

REAR COVER ASSEMBLY
SR.NO.
PART NO
PART NAME
QTY.
1
50.008.12.000
LOCK NUT M12
2
2
P08.D006.001.0.00
STUD M12X1.25X56
2
3
57.507.12.000
PLAIN WASHER M12
2
4
P08.D006.046.0.00
OUTPUT PROTECTION COVER
1
5
P08.D006.003.0.00
CIRCLIPS FOR HOLE Φ55


6
50.008.08.000
LOCK NUT M8
6
7
P08.D006.041.0.00
REAR COVER
1
8
P08.D006.004.0.00
REAR COVER DOWELΦ8*18
2
9
P08.D006.042.0.00
REVERSE GEAR SEAT


10
P08.D006.021.0.00
NEEDLE BEARING


11
57.507.10.000
PLAIN WASHER M10


12
50.911.10.030
FLANGE BOLT M10*30


13
P08.D006.051.0.00
REVERSE GEAR SHAFT


14
P08.D006.052.0.00
REVERSE GEAR


15
P08.D006.022.0.00
WEAR RESISTANT GASKET


16
P08.D006.005.0.00
ELASTIC CYLINDRICAL PIN Φ4×20


17
P08.D006.043.0.00
ROCKER HEAD
1
18
P08.D006.044.0.00
SMALL ROCKLE
1
19
P08.D006.006.0.00
ELASTIC CYLINDRICAL PIN Φ6×25
1
20
P08.D006.023.0.00
FLAT GASKET Φ14*Φ20*2
1
21
P08.D006.024.0.00
OIL SEAL Φ14*Φ22*4
1
22
P08.D006.053.0.00
CLUTCH FORK SHAFT
1
23
P08.D006.025.0.00
O-TYPE RINGS Φ14×Φ2.65
1
24
57.507.12.000
PLAIN WASHER M12
1
25
P08.D006.026.0.00
CLUTCH RESET SPRING
1
26
P08.D006.027.0.00
CLUTCH PLASTIC COVERS
1
27
P08.D006.071.0.00
CLUTCH CONNECTING ROD
1
28
57.507.10.000
PLAIN WASHER M10

29
P08.D006.002.0.00
COTTER PIN 3.2*25

30
P08.D006.045.0.00
UNIVERSAL JOINT


31
908.D003.073.0.00
LONG STICK
32
P08.D003.026.0.00
8PPER PLASTIC COVER

33
P08.D003.027.0.00
BOTTOM PLASTIC COVER


34
P08.D003.010.0.00
PHILIPS COUNTERSUNK HEAD TAPPING SCREWS
ST4X25



.,5/26.$52,/(1*,1(6/,0,7('
$.LUORVNDU*URXS&RPSDQ\

KIRLOSKAR KMW MIN T 8 DLX Specifications

General

Brand	KIRLOSKAR
Model	KMW MIN T 8 DLX
Category	Farm Equipment
Language	English
