HANDLE BAR MOUNTING ASSEMBLY
SR.NO.
PART NO
PART NAME
QTY.
1
P08.D007.051.0.00
STEERING SHAFT
1
2
P08.D007.052.0.00
STEERING POSITIONING PIN
1
3
P08.D007.041.0.00
STEERING SHAFT LOCATING BLOCK
2
4
57.507.12.000
PLAIN WASHER M12
2
5
57.002.12.080
HEX BOLT M12*80
1
6
P08.D007.027.0.00
PROTECTIVE COVER FIXING SUPPORT SLEEVE
3
7
P08.D007.021.0.00
PLANAR STEERING RESET SPRING
1
8
P08.D007.022.0.00
LIFTING HANDLE
1
9
P08.D007.023.0.00
ADJUSTING SPRING
1
10
57.002.10.110
HEX BOLT M10*110
1
11
P08.D007.081.0.00
HANDLE COVER
1
12
P08.D007.025.0.00
UPPER HANDLE PLASTIC COVER
1
13
P08.D007.026.0.00
UNDER HANDLE PLASTIC COVER
1
14
P08.D007.001.0.00
CROSS RECESSED COUNTERSUNK HEAD SCREWS ST4X20
2
15
P08.D007.002.0.00
U SHAPE BOLT M8
2
16
P08.D007.071.0.00
ARM CONNECTING BODY
1
17
50.008.10.000
LOCK NUT M10
3
18
50.008.08.000
LOCK NUT M8
6
19
50.911.08.035
FLANGE BOLT M8*35
2
20
P08.D007.024.0.00
GEAR LEVER HOLDER
2
21
P08.D007.082.0.00
LIMIT PLATE
1
22
50.008.12.000
LOCK NUT M12
1
23
57.507.10.000
PLAIN WASHER M10
2
24
50.911.08.020
FLANGE BOLTS M8*20
2
25
50.911.08.025
FLANGE BOLT M8*25
2
26
50.911.10.075
FLANGE BOLT M10*75
2
27
P08.D007.072.0.00
SHOCK ABSORBING SLEEVE ASSEMBLY
2
28
P08.D007.083.0.00
CONNECTING SEAT OF ARM REST
1
29
P08.D007.084.0.00
GEAR BOARD
1
30
P08.D007.085.0.00
POSITION LIMIT BOARD
1

