14 P08.D008.023.0.00 REVERSE LIMIT SPRING HANDLE 1
15 P08.D008.072.0.00 REVERSE HANDLE LIMIT SPRING SEAT 1
16 P08.D008.084.0.00 UNDER HANDLE PLASTIC COVER 2
17 P08.D008.085.0.00 UPPER HANDLE PLASTIC COVER 2
18 P08.D007.001.0.00
CROSS RECESSED COUNTER SUNK HEAD
SCREWS ST4X20
6
19 P08.D008.086.0.00 LINKAGE SHEET 3
20 50.911.08.045 FLANGE BOLTS M8*45 4
21 P08.D008.087.0.00 TURN AND REVERSE BRACKET 1
22 50.008.08.000 LOCK NUT M8 5
23 50.911.06.040 FLANGE BOLT M6*40 1
24 57.507.06.000 PLAIN WASHER M6 1
25 P08.D008.024.0.00 HANDLEBAR GRIP 2
26 P08.D008.073.0.00 ACCELERATOR SWITCH BRACKET 1
27 P08.D008.074.0.00 THROTTLE SWITCH ASSEMBLY 1
28 P08.D008.025.0.00 THROTTLE CABLE ASSEMBLY 1
29 P08.D008.026.0.00 HANDLE LOCKING CABLE ASSEMBLY 1
30 P08.D008.037.0.00 UPPER CLUTCH CABLE ASSEMBLY 1
31 P08.D008.027.0.00 CLUTCH CABLE ASSEMBLY 1
32 P08.D008.054.0.00 UPPER CLUTCH HANDLE SCREW SHAFT 1
33 P08.D008.028.0.00 UPPER CLUTCH HANDLE RESET SPRING 1
34 P08.D008.029.0.00 UPPER CLUTCH PLATE TRIGGER 1
35 50.008.06.000 LOCK NUT M6 1
36 P08.D008.088.0.00 TURN OFF SWITCH 1
37 P08.D008.075.0.00 TURN OFF SWITCH AND BRAKE BRACKET 1
38 P08.D008.030.0.00 TURN OFF SWITCH HANDLE 1
39 P08.D008.055.0.00 RESET SPRING CONNECTING SHAFT 1
40 P08.D008.031.0.00 TURN OFF SWITCH RESET SPRING 1
41 P08.D008.032.0.00 LEVER HANDLE 2
42 P08.D008.076.0.00 EMERGENCY STOP CABLE ASSEMBLY 1
43 P08.D008.056.0.00 ELASTIC CYLINDRICAL PIN Φ4×20 1
44 P08.D008.033.0.00 CABLE ROLLER 1
45 P08.D008.077.0.00 REVERSE GEAR LEVER 1
46 P08.D008.034.0.00 UPPER PLASTIC LEVER (RED) 1
47 P08.D008.035.0.00 UNDER PLASTIC LEVER (RED) 1
48 P08.D008.036.0.00 CLUTCH LEVER 1
SR.NO
PART NO PART NAME
QTY.
HANDLE BAR ASSEMBLY
.,5/26.$52,/(1*,1(6/,0,7('
$.LUORVNDU*URXS&RPSDQ\
