Kisai Seven - How to Read the Time; Time Display Explanation

• Press button A once to display the time.
• The lights will fade in and the time will be displayed before fading
out.
I. Time
1. How to read the time
Hours are displayed in the
inner ring on the same position
as numbers on a clock. The
position of the gap in this ring
indicates the current hour.
5 minute intervals are
displayed on the outer ring in
the same position as numbers
on a clock. The position of the
gap in this ring indicates the
current five minute group.
Singles minutes 1-4 are displayed above and below the ring. These
are identical and are only shown in two places for design purposes.
If one light is lit on each side, it indicates one minute. If two lights
are lit on each side, it indicates 2 minutes etc.
12
00
+1
+1
+2
+2
+3
+3
+4
+4
30
0555
2535
1050
2040
1545
111
2
10
39
48
57
6
