Door Swing Dimensions
The location must permit both doors to open to a minimum of 90°.
Allow 4¹⁄₂" (11.4 cm) minimum space between the side of the
refrigerator and a corner wall.
NOTE: More clearance may be required if you are using overlay
panels, custom handles, or extended handles on a Classic model.
To adjust the door swing, see “Adjust Doors.”
36" (91.4 cm) Models
42" (106.7 cm) Models
48" (121.9 cm) Models
130˚
130˚
90˚
90˚
110˚
110˚
44³⁄₈"
(112.7 cm
)
39"
(99.1 cm)
14
³⁄₈"
(36.5 cm)
10
⁷⁄₈"
(27.6 cm)
35
¹⁄₂"
(90.2 cm)
38
⁷⁄₈"
(
98.7 cm)
130˚
130˚
90˚
90˚
110˚
110˚
47⁷⁄₈"
(121.6 cm
)
41¹⁄₂"
(105.4 cm)
16
⁷⁄₈"
(42.9 cm)
12
⁵⁄₈"
(32.1 cm)
37
¹⁄₄"
(94.6 cm)
41
³⁄₈"
(105.1 cm)
130˚
130˚
90˚
90˚
110˚
110˚
51³⁄₈"
(130.5 cm
)
44"
(111.8 cm)
19
¹⁄₄"
(48.9 cm)
14
³⁄₈"
(36.5 cm)
39"
(99.1 cm)
43
⁷⁄₈"
(
111.4 cm)
