7
ASSEMBLING THE SIFTER+SCALE ATTACHMENT
To install the Swivel Chute: Lower the
Swivel Chute into the Sifter Housing
at an angle, aligning the marks on the
Swivel Chute with the marks above
the notches on the inside of the Sifter
Housing. Properly installed, Swivel Chute
will be seated securely in the Sifter
Housing and will rotate easily.
1
To install the Sifter Assembly: Lower
the Sifter into the Sifter housing at an
angle so that the drive shaft can be
inserted into the Sifter Housing. Once
the shaft is inserted all the way, press
down on the Sifter, opposite of the
shaft, to click it into place.
2
PRODUCT USAGE
To install the Ingredient Hopper:
Align the Ingredient Valve with the
corresponding notch on the scale, and
lower the hopper onto the scale until
fully seated.
4
To install the scale: Place the scale on
top of the Sifter Housing with the Digital
Scale display facing away from the Stand
Mixer, and slightly left of centre. Twist
the scale counterclockwise until it locks
into place.
3
TIP: Aligning the handle tab on the chute
with one of the notches as you lower the
Swivel Chute into the Sifter Housing will
help you to line up the marks.
